Low Pressure/Vacuum Calibration Standard 19" Rack Mounted

Applications:

• Aircraft manufacturing, government laboratories, oil industry, electric power plants (nuclear and fossil), and general industry
• Pharmaceutical validation and calibration
• Bio-medical quality assurance
• Condenser vacuum

Standard Features:

• 19" Rack Mounted
• Five independent selectable ranges in each instrument
• Available with Light Emitting Diode (LED) or Liquid Crystal Display (LCD)
• Display resolution on 0.02% F.S. typical for each range
• ±0.05% F.S. accuracy for each range
• State-of-the-art pushbutton calibration. No analog potentiometers or adjustments required
• Three different technicians can calibrate the same transmitter and get identical results...every time
• Easy to operate, training can be accomplished in 10 minutes
• Lightweight - less than 30 pounds
• Adjustable overpressure protection
• Precision vernier control
• Self-contained nitrogen cylinder and vacuum converter provides 27" Hg (w/out external pump) to 100 psi
• Voltage/current display mode for transducer testing
• Quick disconnect fitting and hose included

Options:

• 5100 Pressure traps (100 psi and below operation)
